Free On-line SMPS Design Tool
Issue 34, 9th November, 2007
TIPS on PowerEsim
Component Finder

In Core Component Finder, when you select the core, you can see the followings:

  • corresponding material
  • total loss
  • highlighted component loss
  • reject or warning messages
  • Beside, you can also set the number of stack core in this part.

    You can preview the core shape and dimension when highlighting the core.

    What's New?
    Free Full Features access from our sponsors list.

    Click "Free License" on front page to access this sponsors table. Enjoy the free full features PowerEsim.
    Exhibition at 17th China Power Supply Society Conference at Hefei from 19 to 20 Oct, 2007. BC Wire components are accessible by public.

    Detail Specification

    For each power supply design, press button can tune the value of design specification including input section and output section.
