What's New?
2005-12-19: Total number of modeled components in our database : 83696, Recently added component : 4481
Please contact us if you would like to add your components to our database.
2005-12-19: RCC Flyback AC/DC topology is available now.
2005-12-19: Special Bobbin Type is supported in Magnetic Builder.
The RCC self oscillating Converter is now available
  • This is a popular topology for low cost power converters.
  • This flyback topology employs no controller IC and cuts component cost down.
  • This is suitable for low power applications.
  • PowerESim provides a complete schematic diagram together with BOM.
  • It is ready for you to build and test your power supply.
Tips on PowerESim
See the component you pick.

Click onto any component on the circuit diagram and you will come to the component selection page. When you click onto any component on the menu the package and appearance of the component comes up. The diagram also shows a dimension so that you can pick the right component immediately.

Tools Available
Wants a power supply design complete with component placement? On the front page an evaluation design is ready with suggested component placement. It is also ready for thermal simulation. Click on the evaluation design and experience the fun of using PowerESim.

To experience the convenience provided by PowerESim , try it yourself at http://www.powerEsim.com
