| What's New? |
| 2005-12-19: |
Traditional Chinese and Simplified Chinese interfaces are available now. |
| 2005-12-19: |
Total number of modeled components in our database : 83696, Recently added component : 4481
Please contact us if you would like to add your components to our database. |
| 2005-12-15: |
Evaluation designs with Infineon PWM Circuit is available now |
| Evaluation Designs |
 |
PowerESim now offers evaluation designs by which you can evaluate performances of a specific component like a controller IC. Simply click onto the icon on the homepage and you will get a sample power supply design right away. You may use the design for a suggested application or you may modify it for other applications. Circuit diagram, complete bill of materials, a component placement layout are ready for thermal analysis, waveform analysis, loop analysis¡K.. and all analysis that PowerESim provides. Try this direct feature! |
| The Two Wheeler Forward Converter is now available |
|
- The popular Two Wheeler Forward converter is now available on PowerESim.
- This topology is popular for medium to high power applications from 150W onwards.
- Popular for display, computer and server power supplies.
- Both AC input and DC input versions are available.
|
|
| Tips on PowerESim |
How to do a 4 corner operation test?
All power supplies must be checked for operations within the input voltage range and the output load range. The maximum and minimum input voltages, together with the maximum and minimum output currents produce 4 operation corners.
Press <DVT Reports> on the front page. Find the <4 corner tests> button and click. PowerESim will simulate the circuit at the 4 operation corners and show all component stresses in 4 DVT reports. This ensures reliable operations in all defined conditions.
|
| Tools Available |
You may now choose English, Traditional Chinese, or Simplified Chinese as the user interface language. Simply click onto the appropriate button on the front page.
|
|
|
