Free On-line SMPS Design Tool
Issue 33, 23th October, 2007
TIPS on PowerEsim
BOM Builder

In Bom Builder, you can view the list of the BOM.

For each transformer or inductor, press button to export it's generate drawing in EXCEL format.

What's New?
Arnold Magnetic Technologies components are accessible by public. P. Leo UL Insulation System is accessible by public.

Exhibition at Hong Kong Electronics Fair 2007 (Autumn Edition) at HKCEC from 13 to 16 Oct, 2007. Elantas varnish is accessible by public.
Magnetic Builder -- Estimate Loss

In module, you can press button to handle the detail configuration of transformer. Then, you can also press button to estimate the loss of the tranformer.
