Free On-line SMPS Design Tool
Issue 24, 12th March, 2007
TIPS on PowerEsim
Enable ActiveX control

"Internet Explorer" has blocked this site from using an ActiveX control in an unsafe manner. As a result, this page may not display correctly."

When you notice the message above shown at the top banner of the browser, this mean the "ActiveX control" is constrained and some JavaScript actions and Flash movie are disabled. You have to do following things for proper views in PowerEsim.

  • Go to "Internet Options" in IE
  • In the "Security", click on "Customize Levelů"
  • You can find the "Run ActiveX controls and plug-ins" and "Script ActiveX Control marked
  • Check both to "Enable"
  • Restart the browser
  • What's New?
    MAGNETICS Components are accessible by public. Topology VRM 1 Phase DC-DC is accessible by public.

    On-Semi NCP1606 PFC DCM Controller is accessible by public. On-Semi NCP5214 VRM 1 Phase Controller is accessible by public.

    FREE SEMINAR: Designing a 90% efficiency 150W power supply with PFC in hours.
    Only 30% seats left, registrate now.

    Following technique will be discussed in seminar:
  • Active Diode concept and losses reduction
  • Losses saving by reducing EMI component
  • Active EMI IC solution
  • New concept in magnetic design & optimization
  • Importance and ways of choosing the right component
  • Automatic optimization approach
  • Controlling design quality
    Magnetic Builder -- General Drawing
      In General Drawing Page of Magnetic Builder, user can fill in checking parameter, e.g. DC resistance, Magnetizing Inductance and Leakage Inductance, for IQC. Once the check box is clicked, the value between the corresponding pins is enabled for inspection. Simulated value is recommended but user can change the actual IQC specification by change wording in the corresponding text box.
